Description
Our A-Type 3 Tiers Battery Layer Cage is a classic stepped poultry raising system specially designed for commercial egg-laying hen farms. Constructed with premium Q235 steel and hot-dip galvanized anti-corrosion treatment, this 3-tier A-shape cage holds 96–120 laying hens per set, supporting full automatic supporting systems including auto feeding, nipple drinking, rolling egg collection and manure removal.
With open ventilated A-frame structure, it ensures smooth air circulation inside the chicken house, effectively reducing heat stress and disease risk for layers. Compared with stacked H-type cages, A-type design brings easier daily inspection, simpler installation and lower overall farm investment, perfectly matching open, semi-open and closed chicken houses with breeding scale over 5,000 birds. The cage system owns stable load-bearing structure with 15–20 years service life, certified by CE, ISO9001, SONCAP and PVOC, delivering stable egg production and maximum farming profit for medium & large poultry operators worldwide.
| WEDO A-Type 3 Tiers Battery Layer Cage Model Specifications | |||||
| WEDO Model | Tier & Door | Overall Size (L×W×H) | Single Cell Size | Total Cells Per Set | Total Birds Per Set |
| WEDO-A34 | 3 Tiers 4 Doors | 1880×2100×1500 mm | 470×350×380 mm | 24 | 96 |
| WEDO-A34-L | 3 Tiers 4 Doors Large | 2000×2100×1500 mm | 500×350×380 mm | 24 | 96 |
| WEDO-A35 | 3 Tiers 5 Doors | 1950×2100×1500 mm | 470×350×380 mm | 30 | 120 |
| WEDO A-Type 3 Tiers Battery Layer Cage Basic Parameters | |
| Item | Parameter |
| Brand | WEDO |
| Product Name | A-Type 3 Tiers Battery Layer Cage |
| Material | Q235 High Carbon Steel, Hot Dip Galvanized |
| Structure Type | A-Shape Stepped Frame |
| Tiers | 3 Layers |
| Service Life | 15–20 Years |
| Single Set Weight | 80–85 KG |
| Standard Accessories | PP Feeding Trough, Nipple Drinkers, Water Pipe, Egg Rolling Trough |
| Support Automatic System | Auto Feeding Cart, Manure Conveyor Belt, Water Regulator |
| Certifications | ISO9001, CE, SONCAP, PVOC |
| Application | Commercial Egg Laying Hen Farm, Open/Closed Chicken House |
| Custom Service | Cage Size, Layout Drawing, Spare Parts Customization |
| Warranty | 5 Years for Main Frame, 1 Year Free Spare Parts |
WEDO A-Type 3 Tiers Layer Cage Key Features
1. Premium Anti-Rust Material
Whole cage adopts Q235 steel with full hot-dip galvanized treatment, resistant to humid farm environment, long service life up to 20 years.
2. Optimized A-Step Ventilation Design
Open stepped A-frame structure ensures smooth air circulation, reduces heat stress and poultry disease rate, easy daily inspection from both sides.
3. Low Egg Breakage Rate
Built-in 6°–8° sloped egg rolling trough, eggs roll out automatically without collision, greatly cut egg loss.
4. Full Automatic Matching System
Compatible with auto feeding trolley, nipple drinking system and manure removal belt, cut labor cost by 60%+.
5. Stable & Deform-Free Frame
Triangular load-bearing support, firm welding, no deformation under long-term high-density breeding.
6. Wide Compatibility & Easy Installation
Fit open, semi-open and fully enclosed chicken houses; complete installation drawings provided, fast assembly without complex tools.
7. Global Import Certification Support
WEDO factory passes ISO9001 & CE certification, meets Africa, Southeast Asia, Middle East farm import standards.
FAQs
Q: What are your main businesses?
A: We focus on animal feed and breeding equipment.
Q: What feed products do you have?
A: We supply poultry feed, aquatic feed, ruminant feed, pig feed and functional nutritional additives.
Q: What breeding equipment do you offer?
A: We provide cages, feeding systems, laying nests, slatted floors, turnover crates, egg trays and related accessories.
Q: What are the strengths of your feed?
A: Our feed uses premium raw materials and optimized formulas, with stable nutrition and good palatability.
Q: What are the strengths of your equipment?
A: Made of hot-dip galvanized steel for 15-20 years service life. It supports automatic operation and is easy to install and maintain.
Q: Suitable for all sizes of farms?
A: Yes. We have various specifications and one-stop solutions for different farms.
Q: Do you offer customization?
A: Yes. We can customize feed formulas and equipment sizes.
Q: How do you ensure product quality?
A: We have professional R&D, advanced facilities and full-process quality inspection.
Q: What is your delivery time?
A: Normally 7-15 working days after order confirmation.
Q: What after-sales services do you provide?
A: We offer technical guidance, installation guides and long-term after-sales support.40% piglet prestarter concentrate feed.
